Trailer connectors between the trailer and passenger car, light truck or heavy trucks with 12V systems. In Europe, both 7-pin (ISO 1724) and 13-pin (ISO 11446) are common. The 13-pin version being phased in is newer, provides more services than the 7-pin, a more positive locking and also better protection against moisture and contamination.

This is the standard UK wiring of a the normal socket and plug otherwise known as 12N. The diagram below shows the view from outside the vehicle socket (under the flap) and from inside the trailer

Wiring diagrams for 7 pin 12N 'N' type trailer lights plugs and sockets. ... 7 pin 12N wiring diagram. 12 N type plugs are used for road lighting only. ... To wire a plug or socket the first thing to do is to disassemble the plug or socket, this is very simple as the centre part that the wires fasten into can then be removed giving easy access ...

The following trailer wiring diagram(s) and explanations are a cross between an electrical schematic and wiring on a trailer. We recommend these standards because they are pretty universal. That said, for specific situations, there are industrial standards with different connectors and wire arrangements.

12N Standard Socket. 12N electrical kits (socket with black cover) are used for operating the standard lights on the rear of trailers etc. Some newer vehicles with multiplex wiring may need the addition of a bypass relay kit (see Relay section for more information).

Trailer Wiring Connectors. Various connectors are available from four to seven pins that allow for the transfer of power for the lighting as well as auxiliary functions such as an electric trailer brake controller, backup lights, or a 12V power supply for a winch or interior trailer lights.

12V Camper Trailer Wiring Diagram12v camper trailer wiring diagram, 12v electrics for camper trailer wiring diagram, People comprehend that trailer is a car comprised of very complicated mechanics. This automobile is designed not only to travel one location to another but also to take heavy loads. This article will be discussing 12V Camper Trailer Wiring Diagram.

This is the standard UK wiring of a the supplementary socket and plug otherwise known as 12S. There have been slight variations over the years as most newer caravans control the battery charging in the caravan rather than from the towing vehicle.

Other wiring diagrams on this site are listed below: 7 pin ‘S’ type plug and socket wiring diagram. 13 pin Euro plug wiring diagram. 7 way universal bypass relay wiring diagram. Split charge relay wiring diagram. To purchase components for trailer wiring please visit – www.towingandtrailers.com

The 7 pin ‘N’ type (12N) plug will still be used on O1 trailers and many Towbar fitters will still offer the 7 pin Socket as the cheapest alternative. Wiring Diagram for a 13pin Euro trailer plug. Below is a diagram of a 13 Pin Euro trailer plug with coloured pins as they are wired.
